Gantry Crane

Gantry crane is a kind of deformation of bridge crane, also called gantry crane. It is used for loading and unloading of outdoor cargo yard, material yard and bulk cargo. Gantry crane (shaped like a moving door frame gantry crane) has the characteristics of high site utilization, large operation range, wide adaptation, strong versatility, etc., and is widely used in port freight yards.

The main types of gantry cranes include:

• ‌MG gantry crane ‌
• ‌MH gantry crane ‌
• ‌L type gantry crane ‌
• ‌LD gantry crane ‌
• ‌CD gantry crane ‌
• ‌MD gantry crane ‌

‌

Portal crane parameters mainly include:

• Rated load: Refers to the maximum load borne by the gantry crane when it is designed and manufactured, usually expressed in tons.
• ‌Span: Refers to the maximum span range that the gantry crane can cover, usually expressed in meters.
• ‌Lifting height: Refers to the maximum height that a gantry crane can lift items, usually expressed in meters.
• Work level: Reflects its reliability and safety level in different occasions, usually A1, A2, A3, A4, B and other levels.
• Running speed: Refers to the gantry crane in the process of lifting and driving speed, usually expressed in meters per second or meters per minute.
• Power form: Including electric, manual, hydraulic and so on.
• The technical parameters and specifications of different types of gantry cranes:

Weight: 20T, 32T, 50T, 60T, 70T, 80T, 90T, 100T, etc., can be customized according to user needs.

Span: 7M, 8M, 9M, 10M, 12M, 13M, 15M, 19M, 20M, 21M, 22M, 29M, etc., can be selected according to the site conditions suitable span.
